The 1" x 12" x 16" table replaces your installed Die table to add speed and precision to your Punch Workstation. Compatible with the Edwards 100 Ton Deluxe Ironworker. Includes adjustable fences and handles to quickly and easily guide your material for perfect repeatable actions.

Features

• 1" x 12" x 16" Table adds speed and precision to your punch workstation.
• Adjustable fences and handles quickly and easily guide your material for perfect repeatable actions.
• Replaces installed Die Table on 100 Ton Deluxe and 120 Ton Edwards Ironworkers.
• Induction hardened for increased strength.
• Tooth matched at the weld to eliminate blade ticking.

What our Experts Think

• Designed to boost precision and efficiency at the punch station on your ironworker — the 1″ × 12″ × 16″ gauging table increases work surface and control for accurate holemaking.
• Replaces the installed die table on 100 Ton Deluxe (and compatible 120 Ton) ironworkers, upgrading your workstation without additional machines.
• Adjustable fences and handles help guide material consistently, reducing misfeeds and improving repeatability.
• Induction‑hardened construction delivers strength and durability for heavy‑use punch operations.
• Heavy gauge surface supports larger stock and reduces setup time for batch punching jobs.
• Rigid, stable work surface improves operator control and accuracy during high‑capacity punching.
